Description
Rain Bird UNI-Spray 4″ Pop-Up Sprinkler is a compact and reliable spray head for any application. The UNI-Spray accepts all Rain Bird nozzles, including MPR, VAN and U-Series, making it an excellent choice for watering standard and irregular-shaped turf and shrub areas.
For added convenience, these reliable, compact spray heads can be shipped with or without pre-installed Variable Arc Nozzles (VANs) or High Efficiency Variable Arc Nozzles (HE-VAN) that are adjustable from 0° to 360° full-circle operation, saving hours of installation time, effort, and money.
Reliable, Heavy-Duty Materials. Pressure-activated wiper seal prevents excessive flow-by and water waste and keeps debris from entering upon retraction. Rugged cover and body provide durability in high pressure and surge conditions. Plastic and stainless steel materials resist corrosion.
- l Available with pre-installed 10’ (3 m), 12’ (3.7 m), 15’ (4.6 m) and 18’ (5.5 m) VAN nozzles.
- l Small exposed cover makes the unit virtually invisible for more attractive landscapes.
Features
- Small exposed cover makes the unit virtually invisible for more attractive landscapes
- Constructed of durable materials including corrosion resistant stainless steel, assuring long product life even in high pressure or surge conditions
- Pressure-activated wiper seal prevents excessive flow-by and water waste and keeps debris from entering upon retraction
- Two-piece ratchet mechanism allows easy nozzle pattern alignment and provides added durability
Specs
Pressure: 15 to 70 psi (1.0 to 4.8 bar)
Optimum pressure: 30 psi (2.1 bar)
Adjustable nozzle arc range: 0° – 360°
Flow-by: 0 at 10 psi (0.75 bar) or greater; 0.20 gpm (0.04 m³/h; 0.60 l/m) otherwise
Dimensions
Dimensions: 1/2″ (15/21) NPT female threaded inlet
Body Height: 5 7/8″ (14.9 cm)
Exposed Surface Diameter: 1 1/4″ (3.2 cm)
For more information, please visit Rain Bird’s website.
